Dendritic Modified PA-CF MAX 3D Printer Filament

Dendritic Modified PA-CF MAX 3D Printer Filament

PA-CF is a carbon fiber reinforced nylon filament based on PA6. it has extremely high strength andrigidity. The tensile strength of the material can reach more than 100MP, and the continuous usetemperature can reach 150°c. Such excellent performance enables printed parts to replace metalparts in many occasions. Moreover, this filament adopts special anti-print blocking technology, andthe material is modified with dendritic polymers of special structure, which greatly improves thefluidity of the material while maintaining the original performance. The technology of anti-printblocking solves the problem of printing heads of carbon fiber filaments in the past. Small-caliberprint nozzles can be selected, which greatly improves the printing accuracy and printing quality.

Consult

Features Technical Indicators Overall Dimension

1、Optimum PrintingTemp: 245-270°C
2、Bed Temp:0/65°C
3、Feeding Speed: 30~90mm/s
4、Walking Speed: 90~150mm/s

Material type	HDT℃	MFR g/10min	Tensile Strength MPa	Elongation at Break%	Flexural Strength Mpa	Flexural Modulus MPa	Lzod impact strength KJ/m³
Material type	ASTM D648 (@1.82MPa)	ASTMD-1238 (220℃/10Kg)	ASTM D-638	ASTM D-638	ASTM D-790	ASTM D-790	ASTM D-256
PA-CF	120	6	85	26	122	5500	15.5
Normal PA	58	3.5	53	35	51	1300	9
